Heat Conductive Potting Silicone TS8822 Two-component silicone potting, 1 to 1, curing at room temperature. Features & Benefits REACH, ROHS, certified Good waterproof Good thermal conductivity Easy to mix and use
Features & Benefits of Heat Conductive Potting Silicone TS8822
Two-component silicone potting, 1 to 1, curing at room temperature.
◆ REACH, ROHS, certified
◆ Good waterproof
◆ Good thermal conductivity
◆ Easy to mix and use
Application of Heat Conductive Potting Silicone TS8822
◆ Power moduls
◆ Adaptors
◆ Transformers
◆ Ballasts
◆ Sensors
◆ Electric control units product
Description of Heat Conductive Potting Silicone TS8822
Tensan silicone 1 to 1 encapulants are supplied as two part liquid component kits.
After mixing, two parts silicone will be cured as a flexible elastomer, which is well used for the protection of electrical and PCB system assemble application.
The duration of application and the curing time at room temperature are independent of the number of materials.
Packing Information of Heat Conductive Potting Silicone TS8822
20KG/25KG/BUCKET
24 BUCKET/PALLET
Storage andValidity
Stored in room temperature, and in a cool, ventilated, dry place.
Shelf life: 6 month
Typical Properties of Heat Conductive Potting Silicone TS8822
Item |
Index |
Color |
Gray|Black |
Viscosity mPa·s (25℃) |
Part A: 3500 Part B: 3500 |
Specific Gravity ( Cured ) |
1.60 |
Mix Ratio |
1:1 |
Viscosity mPa·s (25℃) |
4500 |
Density g/cm3 (25℃) |
1.60 |
Working Time at 25℃ (minutes) |
30-60 |
Heat Cure Time Hr/℃ |
0.5/80 |
Hardness (Shore A) |
45 |
ThermalConductivity (W/mK) |
0.7 |
DielectricConstant (1MHz 25℃) |
2.8 |
Dielectric Strength kV/mm (25℃) |
24 |
VolumeResistivity (DC500V ) Ω· cm |
1.5×1015 |
UL 94 Flame Classification |
V-1 |
