Welcome to buy Excellent Heat Resistance Silicone Encapsulant Waterproof from us. Every request from customers is being replied within 24 hours. Features & Benefits of Thermal Conductive Potting TS8866 Two-component silicone potting, 1 to 1, curing at room temperature. REACH, ROHS, certified Good waterproof Good thermal conductivity Easy to mix and use
Excellent Heat Resistance Silicone Encapsulant Waterproof
Descriptions
Tensan silicone 1 to 1 encapulants are supplied as two part liquid component kits.
After mixing, two parts silicone will be cured as a flexible elastomer, which is well used for the protection of electrical and PCB system assemble application.
The duration of application and the curing time at room temperature are independent of the number of materials.
Features & Benefits
Two-component silicone potting, 1 to 1, curing at room temperature.
◆ REACH, ROHS, certified
◆ Good waterproof
◆ Good thermal conductivity
◆ Easy to mix and use
Data Sheet
|
Item |
Index |
|
Color |
Part A: Gray/ gray
|
|
Viscosity mPa·s (25℃) |
Part A:4500 Part B: 3500 |
|
Specific Gravity ( Cured ) |
1.9 |
|
Mix Ratio |
1:1 |
|
Viscosity mPa·s (25℃) |
4200 |
|
Density g/cm3 (25℃) |
1.60 |
|
Working Time at 25℃ (minutes) |
30-60 |
|
Heat Cure Time Hr/℃ |
0.5/80 |
|
Hardness (Shore A) |
50 |
|
ThermalConductivity (W/mK) |
0.7 |
|
DielectricConstant (1MHz 25℃) |
2.5 |
|
Dielectric Strength kV/mm (25℃) |
>18 |
|
VolumeResistivity (DC500V ) Ω· cm |
1.5×1015 |
|
UL 94 Flame Classification |
94 V-1 |
Applications
◆ Power moduls
◆ Adaptors
◆ Transformers
◆ Ballasts
◆ Sensors
◆ Electric control units product
Packing Information
20KG/25KG/BUCKET
24 BUCKET/PALLET
Storage and Validity
Stored in room temperature, and in a cool, ventilated, dry place.
Shelf life:6 month
